Performance Climate Changer® Semi-Custom Air Handlers

Performance Climate Changer Semi-Custom Air Handler PSCA Closed front

Overview

Performance® Climate Changer Semi-Custom Air Handlers

Versatility meets high performance — Trane Performance Climate Changer® Semi Custom Air Handlers combine flexibility and reliability to meet your project requirements.

Application: Indoor, outdoor
Airflow Range: 15,000 – 60,000 CFM
Construction: 2” or 3” Foam-Injected Double Wall no through-metal construction

Versatility

Suitable for indoor and outdoor applications, these units offer a wide array of options designed to reduce environmental impact, support sustainability goals, and lower cost of ownership. Optional flexible aspect ratio available.
Energy Efficiency

Units feature superior casing that provide low air leakage rates. Choose the fan option that best meets your performance goals ꟷ from sustainability, to redundancy, to energy efficiency, to keeping operating costs down. Advanced energy recovery options further enhance efficiency.
Engineered for Indoor Environmental Quality

Innovative technologies like Trane Commercial Air Purification System (TCAPS) and Cool Dry Quiet (CDQ®) desiccant dehumidification technology provide dramatically improved indoor air quality without compromising acoustical performance.
Reliable High Performance

Units offer reliable performance with up to 60,000 CFM and +/-10” static pressure capabilities. Designed for longevity with double-wall casing with 2” or 3” injected foam walls to minimize leakage and deflection. Direct Drive Plenum fan arrays provide reliable, low-maintenance performance.
Easy Installation & Maintenance

Units are designed for easier installation, reducing costly downtime. Engineered with removable panels with optional multiple shipping splits, making it easier to navigate through narrow spaces. Factory-installed controls simplify job-site coordination and reduce installation time and expense.
Secure, Open, Easy Connectivity

Symbio 500 seamlessly connects with Trane Building Automation and Management Systems, including Tracer SC+ and Tracer Synchrony or Tracer Ensemble. Units run on industry standard BACnet, so Symbio can be integrated into both Trane BAS and non-Trane systems.

Product Information

Key Features

2" or 3" injected foam walls (R-13 or R-19) with no through-metal design to help reduce air leakage and deflection and to maximize energy efficiency
Building Connectivity—Optional factory-mounted Symbio 500 controls allow for system optimization from the first day of commissioning
Up to +/-10” Static Pressure Capabilities
Flexible fan and coil options to meet performance requirements
Creative Dehumidification and Energy Recovery Solutions including Cool Dry Quiet (CDQ), Sensible Assisted Membrane (SAM), and traditional energy recovery wheels and air-to-air heat exchangers
Split dehumidification unit layout for improved humidification control
Sound data rated in accordance with AHRI 260
Factory leakage and deflection testing

Model Specifications

Application: Indoor, outdoor
Airflow Range (Cfm): 15,000 – 60,000 CFM
Construction: 2" or 3" Foam Double Wall no through-metal construction.
Casing Pressure: Up to +/-10" Static Pressure Capabilities
Deflection Ratio: L/240
Air Cleaning: 2", 4" cartridge, 18" / 30" bag, 12" cartridge, HEPA, Carbon, UV lights, TCAPS
Coil Options: Hydronic, Refrigerant, Steam, Electric, Gas, Integral Face and Bypass
Fan Options: Direct Drive Plenum, Motorized Impellers, Housed Fans

Semi-Custom Air Handler Options

Trane offers a variety of options that can be incorporated into our Custom Air Handlers. These factory-packaged solutions enable simplified on-site installation, and provide proven, tested performance.

Motorized Impeller Fan Array

An electronically commutated motor (ECM) array that addresses the application and installation challenges faced when selecting and installing an air handler fan section.

Learn More
Cooling Coils and Heating Coils for Air Handlers

Trane cooling coils and heating coils for air handlers are optimized for a range of pressure drop and capacity requirements.

Learn More
TCACS Catalytic Air Cleaning System

Enhance indoor air quality with Trane TCACS catalytic cleaning system, featuring advanced filtration and germ-killing UV light. Ideal for commercial settings.
Energy Recovery Options

Trane offers energy recovery options that responsibly and often cost-effectively repurpose existing, discarded heat for use elsewhere in the building.
Sensible Assisted Membrane Heat Exchanger

Sensible Assisted Membrane utilizes membrane exchangers and reduces or removes the leakage potential from the building exhaust air path.
Symbio® Equipment Controllers

Trane® Symbio® Equipment Controllers maximize energy efficiency and flexibility, offering seamless integration, remote connectivity, and enhanced serviceability for various HVAC systems.
