Voyager® Rooftop Units

12.5 - 25 Tons, 27.5 - 50 Tons

Voyager® Rooftop Units

Voyager® Rooftop Units

12.5 - 25 Tons, 27.5 - 50 Tons

Key Features:

  • Available in gas/electric, electric/electric & heat pump only for Voyager 2
  • Dependable MERV filtration that removes contaminants as small as 0.3 microns
  • Fast delivery to keep projects on track and sites up and running
  • Energy efficient performance lowers costs without sacrificing comfort
  • Engineered for performance and durability
  • Connected-ready to optimize HVAC performance
  • Fully customizable
  • Designed-in features simplify installation and service
  • Trane quality guarantee

Need a rental? Learn more about our Rental Services

Get it Faster from Trane.

We know time is money. You can have your Voyager unit in two to three weeks – the fastest delivery in the industry – to help keep projects on track and get job sites up and running quickly.

Choose from two models to meet the needs of a broad range of small, medium to large commercial buildings:

Voyager 2 - 12.5 - 25 Tons

Voyager 3 - 27.5 - 50 Tons

Energy efficient comfort with lower operating costs

  • ASHRAE 90.1 and Energy Star compliant
  • Up to 20.1 IEER on Voyager 2 with eFlex technology cooling, gas/electric models
  • Voyager 2 dual compressors provide outstanding humidity control, light load cooling and system backup
  • Optional Trane eFlex™ variable-speed compressors and fans deliver ultra-high efficiency
  • Variable air volume (VAV) options service single- and multi-zone applications
  • Optional Trane eStage™ compressors deliver increased full and part load efficiences on Voyager 3

Performance and durability you can rely on

  • High efficiency filtration with MERV 8, MERV 13, and MERV 14 filters to remove contaminant particles as small as 0.3 microns
  • Hot gas reheat recycles heat energy from compressor to reduce indoor air humidity
  • Unique coil design uses less refrigerant
  • All-aluminum microchannel (MCHE) condenser coils provides extra durability
  • Foil-faced insulation edges prevent fibers from entering the airstream and clogging filters
  • Coating options to protect against corrosion
  • Easy chemical-free cleaning

Optimize HVAC performance with building connectivity

  • Integrated microprocessor controls manage heating, cooling and ventilation
  • Trane Pivot® Smart Thermostat – with remote monitoring app
  • Outputs to connect to building automation system and expanded diagnostics
  • Optional Trane Human Interface for faster commissioning, troubleshooting and maintenance
  • Add 24/7 peace of mind with Trane Intelligent Services

Multiple custom options - Voyager is not one-size-fits-all

Dozens of factory-installed options include:

  • Trane® Air-Fi Wireless connectivity
  • CO2 sensor wiring
  • Fault detection diagnostics
  • High-efficiency motors and filtration
  • Multiple-zone VAV controls and more

Designed to make your job easier

  • Standardized components
  • Color-coded and numbered wiring (Voyager 2)
  • No field conversion required for downflow or horizontal
  • Quick-access panels
  • Single-side service

Quality you can count on – guaranteed

Trane backs up Voyager with an outstanding warranty:

  • 10 years on stainless steel heat exchanger
  • 5 years parts-only on compressor
  • 5 years on low-leak economizer
  • 1 year on all standard parts
  • Extended warranty options for additional peace of mind

Specifications

Voyager 2 - 12.5 - 25 Tons

Nominal Cooling Ton Size Cooling Stages AHRI Efficiency IEER (STD Gas Heat/Multi Speed Fan) Low Gas Heating (Input/Output) (MBtub) Medium Gas Heating (Input/Output) (MBtub) High Gas Heating (Input/Output) (MBtub) Approx. Unit Weight (lbs) Gas Heat Approx. Unit Weight (lbs) Electric Heat
12.5 2 13.5 150/120 350/280 250/200 1448 1373
15 2 13.2 250/200 350/280 350/280 1838 1763
17.5 2 13.2 250/200 350/280 350/280 1894 1819
20 2 12.4 250/200 350/280 350/280 1977 1902
25 2 12.4 250/200 350/280 350/280 2020 1945

Voyager 3 - 27.5 - 50 Tons

Nominal Cooling Ton Size Cooling Stages AHRI Efficiency IEER (STD Cooling Only/ VAV Fan) AHRI Efficiency IEER (HI Cooling/ VAV Fan) Low Modulating Gas Heating (Input/Output) (MBtuh) High Gas Heating (Input/Output) (MBtuh) High Modulating Gas Heat Turndown Approx. Unit Weight (lbs) Cooling Only
27.5 2 to 5 12.4 13.6 350/280 600/480 5 : 1 3590
30 2 to 5 12.0 13.3 350/280 600/480 5 : 1 3665
35 2 to 5 12.6 13.6 350/280 600/480 5 : 1 3746
40 3 to 5 11.8 14.7 350/280 750/600 5 : 1 4565
50 3 to 5 12.3 14.5 350/280 750/600 5 : 1 4827

Factory Installed Options and Field Accessories

Verify availability with your local Train rep or ordering system.

  • Trane® Air-Fi™ Wireless components
  • CO2 Sensor Wiring
  • Complete Coat™ Condenser Coil
  • Corrosion Protected Condenser Coil (Voyager 3)
  • Circuit Breaker (Required with Through-the-Base Electrical)
  • Condensate Overflow Switch
  • Dehumidification (Hot Gas Reheat)
  • Disconnect Switch (Required with Through-the-Base Electrical)
  • Fault Detection & Diagnostics (FDD)
  • High Efficiency Filtration
  • High Efficiency Motors
  • High Fault Short Circuit Current Rating (SCCR)
  • Hinged Access Doors
  • Human Interface
  • Modulating Gas Heat with a 2.5:1 or 5:1 Turndown Ratio
  • Multi-Speed Indoor Fan System (Voyager 3)
  • Multiple-Zone VAV Control
  • Novar Unit Controls (Voyager 3)
  • Powered or Unpowered Convenience Outlet
  • Single Zone VAV - One Zone Variable Air Volume Mode
  • Stainless Steel Drain Pan
  • Stainless Steel Heat Exchanger
  • Supply, Return, and Plenum Air Smoke Detector (Voyager 3)
  • Through-the-Base Electrical Utility Access
  • Through-the-Base Gas Piping (Gas/Electric Only)
  • BACnet™ Communications Interface
  • Clogged Filter/Fan Failure Switch
  • Discharge Air Temperature Sensing Kit
  • Economizer - Standard
  • Economizer - Low Leak
  • Electric Heaters
  • Frostat™ - frost prevention kit
  • Indoor Fan Motor Shaft Grounding Ring
  • LonTalk® Communications Interface
  • Oversized Motors
  • Reference or Comparative Enthalpy
  • ReliaTel Options Module (RTOM)
  • Tool-less Hail Guards
  • Trane Communication Interface (TCI)
  • Traq™ outside air measurement (Voyager 3)
  • Statitrac™ direct space pressure control (Voyager 3)
  • 50% & 100% Power Exhaust Fans (Voyager 3)

Field-Installed Components

  • CO2 Sensor - Demand Control Ventilation (DCV)
  • Dampers (Voyager 2)
  • Digital Display Zone Sensor
  • Economizer - Standard, Horizontal (Voyager 2)
  • Economizer - Low Leak, Downflow & Horizontal (Voyager 2)
  • Humidity Sensor/Humidistat
  • LP Conversion Kit (Voyager 2)
  • Powered Exhaust (Voyager 2)
  • Remote Potentiometer
  • Roof Curbs
  • Static Drive Accessories (Voyager 2)
  • Ventilation Override Accessory
  • Wireless Zone Sensor
  • Zone Sensors/Thermostats

Easy Install and Maintenance Features

  • Color-coded (Voyager 2) and numbered wiring for low voltage connections, as simple as 1-1, 2-2, 3-3
  • Easy access low voltage terminal board
  • Fork pocket access from three sides
  • Quick-access panels to reach standardized components and wiring
  • Single-point power connection
  • Single-side service
  • Non-corrosive, sloped drain pans
  • Improved cabinet integrity against moisture with 1-1/8” lip around supply and return downflow units
  • Crankcase heaters to warm oil standard on all Voyager models
  • Discharge line thermostat standard for extra protection to compressor
  • Anti-short cycle timer with three-minute minimum “on” and “off” to assure proper oil return to compressor
