Trane Energy Storage Tanks

An "HVAC" battery for your cooling system

  • ctv-chiller-service-tech.jpg

    Sustainable

    Designed to help lower environmental impact by storing renewables and and clean energy during off-peak periods. Our energy storage tanks are made of non-corroding materials of construction which is 99% reusable or recyclable

  • two-people-discussing-plans.jpg

    Reliable

    Not only are our tanks backed by a 10 year limited warranty they can last over 35 years.

  • Asian engineer wearing glasses working in the boiler room,maintenance checking technical data of heating system equipment,Thailand people

    Flexible

    Modular design so you can add more capacity over time and relocated them easily.

Nighttime in the middle of a city

Store clean, less expensive energy

Energy storage tanks shift all or a portion of a building’s cooling needs to off-peak, night time hours. They store energy in the form of ice during off-peak periods when utilities generate electricity more efficiently with lower energy and demand charges. The stored ice is then used to cool the building occupants the next day, during the peak periods when utility rates are at their highest.

TC_energy storage trends and gauges resize.png

Shift all or some of your thermal loads

There are any number of control strategies that can be utilized to take advantage of the benefits of thermal energy storage. However, there are two basic approaches that define the common limits of system design. Electric rates and building usage will determine which control strategies are best for the project.

  • Full Storage A chiller sized large enough to charge enough energy storage can shift the entire load to off-peak periods.
  • Partial Storage The chiller works in conjunction with the CALMAC energy storage tanks during on-peak periods to manage the building’s cooling load. During off-peak hours, the chiller charges the tanks for use during the next day’s on peak cooling period.
Glycol Management System.jpg

Glycol Recommendations

A secondary fluid is needed that can operate and flow at temperatures low enough to freeze water. An ethylene-based or propylene-based glycol solutions is recommended. A premixed solution of an industrial heat transfer solution that is specially formulated for low viscosity and superior heat-transfer properties should be used. Industrial based HTF’s contain a multi-component corrosion-inhibitor system that can be maintained and provide a long useful life.

Technician_Customer_iPad_Calmac Ice Tanks_2018.jpg

Virtually Maintenance Free

You can maintain your CALMAC tanks and the energy storage system by using a maintenance process similar to that used for conventional cooling.

  • Perform chiller maintenance as required.
  • Ensure the controls are operating properly and in sync with the utility rates.
  • Check the health of the glycol fluid annually.
  • Check the water level in the tanks.
  • Add biocide as needed to eliminate algae growth.
