M Series Description

The M Series air handlers combine affordability and flexibility to work with the complete range of Trane heating and cooling products. So you get the reliability of Trane and the options to work within your specific system and budget.

Overview

-

Reliability

The all-aluminum coil found in the M Series residential air handlers is exponentially more durable than standard copper coils, which are susceptible to formicary corrosion. These all-aluminum coils ensure families stay comfortable indoors all year long, no matter what the weather outside.

Rust prevention

Trane residential air handlers come with a no-rust polymer drain pan along with galvanized cabinet features to keep things running and looking good for a long time.

Matched options made right

The introduction of the M Series residential air handlers allows more flexibility for addressing special applications for all of your heating and cooling needs. Additionally, The TEM6 residential air handler has a variable speed motor, and Comfort-R technology, offering efficient home comfort at a price that is easy on the wallet.

Specifications

-

TEM6 Variable Speed air handler models

modelnominal cooling capacity (btuh)nominal tonsheight (in.)width (in.)depth (in.)
TEM6A0B24H24000246.7718.521.13
TEM6A0B30H300002.546.7718.521.13
TEM6A0C36H36000351.2723.521.13
TEM6A0C42H420003.551.2723.521.13
TEM6A0D48H48000453.8726.521.13
TEM6A0D60H60000553.8726.521.13

TEM4 Convertible air handler models

modelnominal cooling capacity (btuh)nominal tonsheight (in.)width (in.)depth (in.)
TEM4A0B18S21SA180001.54518.521
TEM4A0B24S21SA2400024518.521
TEM4A0B30S31SA300002.54518.521
TEM4A0C36S41SA3600035123.521
TEM4A0C42S41SA420003.55123.521
TEM4A0C48S41SA4800045123.521
TEM4A0C60S51SA6000055123.521

TEM3 Convertible air handler models

modelnominal cooling capacity (btuh)nominal tonsheight (in.)width (in.)depth (in.)
TEM3A0B1818,0001.54518.521
TEM3A0B2424,00024518.521
TEM3A0B3030,0002.54518.521
TEM3A0B3636,00034518.521
TEM3A0C4242,0003.55123.521
TEM3A0C4848,00045123.521
TEM3A0C6060,00055123.521

Trane M Series air handlers offer a variable speed motor and Comfort-R technology for reliable comfort and efficiency, like only a Trane can. The M Series air handler includes:

  • Variable speed blower motor
  • Comfort-R humidity control
  • 4-way convertible line
  • Galvanized steel cabinet
  • Optional electric heat
  • All-aluminum coil
  • No-rust polymer drain pan
  • Cooling and heat pump systems available
