XL16i

XL16i
ESTIMATED PRICE*
PRICE RANGES: Price reflects the most common average installation cost in your area based on a 3 ton unit. Price ranges shall apply to basic installation. All price ranges are subject to adjustment based on the unique characteristics and location (i.e. zip code) of the home. Any changes or modifications to Basic Installation agreed upon by Buyer will be an additional cost as negotiated by Buyer and the independent Trane Comfort Specialist™ including ductwork. See more details
No Information
Pricing and specialist vary by location
Valid zip code not detected
Change your ZIP code for new results.
Please enter a valid zip code

What's Included

  • Coil
    The coil, also known as an indoor coil or evaporator coil, is the part of your air conditioner or heat pump that regulates the temperature in your house all year long. The coil does this by absorbing the moisture and heat in your home. There can be no cold air without the evaporator coil.
    Included
  • Thermostat
    A thermostat is a device that automatically regulates temperature, or that activates a device when the temperature reaches a certain point. A thermostat can either be standard or Wi-Fi connected, either of which is dependent on your individual needs.
    Included
  • Condenser Pad
    Your outdoor unit sits on top of waterproof/weatherproof condenser pad to provide a flat stable surface to keep your outdoor unit secure and in place for optimal performance. The condenser pad also raises your outdoor unit off the ground thus protecting it from moisture as well as pests and insects.
    Included
  • Whip
    Whips are wires in a weather proof casing for outdoor use. They are used to connect the 220 volt power to your outdoor unit, in some locations a licensed electrician is required.
    Included
  • Electrical Disconnect
    This service switch permits a service technician to work safely on equipment by turning off electrical power to the unit. The switch is typically on a building wall near the outdoor unit.
    Included
  • Flush existing refrigerant line set or install new line set
    Insulated copper piping which carries the refrigerant (produces cooling effect) from the outdoor unit to indoor unit. The insulation protects any condensation from leaking into your home.
    Included
  • Clean up after installation
    Included
  • Removal and disposal of old system
    Included
  • Install new system by local code
    Included
  • Reconnect to existing ductwork
    Connect to existing ductwork (conduits or passages used in heating, ventilation and air conditioning to deliver and remove air. Air ducts ensure acceptable indoor air quality as well as thermal comfort *)

    * Does not include any new ducts that may be needed for your specific home needs
    Included
SEER:
The higher the SEER, the less fuel you’ll need to keep your home comfortable, the less you’ll spend on energy, and the lower your carbon footprint will be.
Up to 17
Nominal Sound:
The average sound level in decibels. The higher the number, the louder the unit. For example, a vacuum cleaner = 70.
69
Cooling Stages
Units with variable cooling stages have more precise temperature control and operate more efficiently than single stage units.
ONE
Energy Savings:
Yearly energy savings based on the ratings of a matched system. The majority of systems installed prior to 2006 are 10 SEER or lower.
54%
SAVE 54%
Save an average of 54 on energy costs † with this unit

XL16i DESCRIPTION

Air Conditioner System

XL16i

ESTIMATED PRICE*
PRICE RANGES: Price reflects the most common average installation cost in your area based on a 3 ton unit. Price ranges shall apply to basic installation. All price ranges are subject to adjustment based on the unique characteristics and location (i.e. zip code) of the home. Any changes or modifications to Basic Installation agreed upon by Buyer will be an additional cost as negotiated by Buyer and the independent Trane Comfort Specialist™ including ductwork. See more details
No Information
Pricing and specialist vary by location
Valid zip code not detected
Change your ZIP code for new results.
Please enter a valid zip code

What's Included

  • Coil
    The coil, also known as an indoor coil or evaporator coil, is the part of your air conditioner or heat pump that regulates the temperature in your house all year long. The coil does this by absorbing the moisture and heat in your home. There can be no cold air without the evaporator coil.
    Included
  • Thermostat
    A thermostat is a device that automatically regulates temperature, or that activates a device when the temperature reaches a certain point. A thermostat can either be standard or Wi-Fi connected, either of which is dependent on your individual needs.
    Included
  • Condenser Pad
    Your outdoor unit sits on top of waterproof/weatherproof condenser pad to provide a flat stable surface to keep your outdoor unit secure and in place for optimal performance. The condenser pad also raises your outdoor unit off the ground thus protecting it from moisture as well as pests and insects.
    Included
  • Whip
    Whips are wires in a weather proof casing for outdoor use. They are used to connect the 220 volt power to your outdoor unit, in some locations a licensed electrician is required.
    Included
  • Electrical Disconnect
    This service switch permits a service technician to work safely on equipment by turning off electrical power to the unit. The switch is typically on a building wall near the outdoor unit.
    Included
  • Flush existing refrigerant line set or install new line set
    Insulated copper piping which carries the refrigerant (produces cooling effect) from the outdoor unit to indoor unit. The insulation protects any condensation from leaking into your home.
    Included
  • Clean up after installation
    Included
  • Removal and disposal of old system
    Included
  • Install new system by local code
    Included
  • Reconnect to existing ductwork
    Connect to existing ductwork (conduits or passages used in heating, ventilation and air conditioning to deliver and remove air. Air ducts ensure acceptable indoor air quality as well as thermal comfort *)

    * Does not include any new ducts that may be needed for your specific home needs
    Included
Home cooling with the Trane XL16i offers flexible family comfort, with the ability to cool every room to the right temperature efficiently. So even the hard-to-cool parts of your home will be easy to relax in.

More Details

ENERGY STAR logo
ENERGY STAR Qualified*
TOTAL ESTIMATED INSTALLED PRICE *Estimated price reflects the most common average installed cost across the USA. Price may vary in your area. See more details

Overview

-

Efficient performance

The XL16i’s SEER rating of up to 18.0 makes it an energy-efficient choice for home comfort.

Durable and economical

Increased efficiency may substantially lower your home cooling costs. Materials for all components are tested again and again for long-lasting performance and durability.

Cleaner, healthier indoor air

Add Trane CleanEffects® Whole Home Air Cleaner to your system for advanced air filtration that removes more dust, pollen and other irritants from conditioned air for a cleaner, healthier, more comfortable home.

Product Brochure

Specifications

-

Single-stage XL16i air conditioner models

MODEL COOLING CAPACITY (BTUH) NOMINAL TONS HEIGHT (IN.) WIDTH (IN.) DEPTH (IN.) Energy Guide
4TTX6018J 18,000 1.5 37 33 30 Energy Guide
4TTX6024J 24,000 2 37 33 30 Energy Guide
4TTX6030J 30,000 2.5 44 37 30 Energy Guide
4TTX6036J 36,000 3 46 37 34 Energy Guide
4TTX6042J 42,000 3.5 54 37 34 Energy Guide
4TTX6048J 48,000 4 54 37 34 Energy Guide
4TTX6049J 48,000 4 54 37 34 Energy Guide
4TTX6060J 57,500 5 54 37 34 Energy Guide
4TTX6061J 60,000 5 54 37 34 Energy Guide

Every Trane air conditioner is packed with high-quality components. Each helps ensure that time after time, your unit will provide total comfort your family can rely on. The XL16i includes:

  • Durable Climatuff™ compressor
  • Full-side louvered panels
  • WeatherGuard™ II top
  • Baked-on powder paint
  • Corrosion-resistant Weatherguard™ fasteners
  • All-aluminum Spine Fin™ outdoor coil
  • DuraTuff™ non-corrosive base pan
  • Unique mounting of shaft down fan motor
  • Variable-speed fan motor*
  • Quick-Sess cabinet with full coil protection
  • Low sound with advanced fan system and sound insulators on compressors (on select models)
*Only available in select models. Please ask your dealer for more information.
